Please Contact Us to Order to offer competitive prices and delivery time for S+S REGELTECHNIK - 1301-1112-2010-000 Differential pressure transmitter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | S+S REGELTECHNIK |
| Product | 1301-1112-2010-000 |
| Description | Differential pressure transmitter |
| Internal code | ONR2894084 |
| Weight | 0.4 |
| Technical specification | Power consumption < 1 W at 24 V DC; < 2 VA at 24 V AC Voltage supply 15...36 V DC depending on working resistance, residual ripple stabilised ± 0.3 V Working resistance Ra (ohm) = (Ub -14 V)/ 0.02 A for I variant Measuring function Differential pressure, volume flow (square root output signal) Current consumption < 20 mA Measuring ranges multi-range switching with 8 switchable measuring ranges Media temperature -20...+50°C Pressure connection with connection nozzles for pressure hose Ø 6 mm Type of pressure differential pressure Zero point offset ± 5 % of final value Above- below-pressure max. 5 x pressure range Medium clean air and non-aggressive, non-combustible gases Signal filtering switchable 1 s/ 10 s Output 4...20 mA Electrical connection 2- or 3-wire connection 0.14 - 1.5 mm² via terminal screws Output signal 4...20 mA Cable connection cable gland, plastic (M 16 x 1.5; with strain relief, exchangeable, max. inner diameter 10.4 mm) or M12 connector according to DIN EN 61076-2-101 (optional on request) Cable gland M 16 x 1.5, including strain relief, exchangeable, max. inner diameter 10.4 mm Long-term stability ± 1 %/ year Hysteresis 0.3 % of final value Media contacting parts ms, Ni, Nylon, PU, Si, PVC with plasticisers Temperature drift values ± 0.1 % of final value/ °C Linearity < ± 1 % of final value Air humidity < 95 % r. H., non-precipitating air Accuracy (1000 Pa): ± typically 10 Pa compared to the calibrated reference device Protection class III (according to EN 60 730) Protection type IP 65 (according to EN 60 529)* Standards CE conformity, electromagnetic compatibility according to EN 61326, according to EMC Directive 2014/ 30/ EU Measuring range pressure 0 ... +100 Pa / -100 ... +100 Pa 0 ... +300 Pa / -300 ... +300 Pa 0 ... +500 Pa / -500 ... +500 Pa 0 ... +1000 Pa / -1000 ... +1000 Pa Housing plastic, UV-stabilised, material polyamide, 30 % glass-globe reinforced, with quick-locking screws (slotted/ Phillips head - combination), colour traffic white (similar to RAL 9016), housing cover for display is transparent ! Housing dimensions 72 x 64 x 43.3 mm (Tyr 1 with Display) Features two-line display with illumination, cutout approx. 36 x 15 mm (W x H), to display ACTUAL pressure |
