Please Contact Us to Order to offer competitive prices and delivery time for RTK Regeltechnik - 15042085/010 Engine control valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | RTK Regeltechnik |
| Product | 15042085/010 |
| Description | Engine control valve |
| Internal code | ONR3342713 |
| Weight | 12 |
| Technical specification | Series MV 5211 in passageway form Nominal diameter DN 15, nominal pressure PN 25 Housing material nodular cast iron EN-GJS-400-18-LT Flanges with sealing surface according to DIN Spindle seal: Roof Collars PTFE/Carbon Character/Instray: Equestrous/under the keg Parabolic cone, metallic sealing Kvs-value = 1 m3/h, stroke 25 mm Seat diameter: 8 mm Surface treatment with zinc dust primer max. permissible pressure according to DIN EN 1092 max. permissible temperature TS 250 °C Electric actuator - type ReAct 30E-028 Actuating force 3 kN, including manual adjustment AC motor 230 V, 50/60 Hz Adjustment speed 0.28 mm/s, stroke 25 mm Degree of protection IP 65 with pillars Additional equipment: - additional limit switches (2 pieces) - Potentiometer 1000 Ohm |
