Please Contact Us to Order to offer competitive prices and delivery time for Sor - 1B4-K45-M4-C1A-PBTTCLA5 SOR PRESSURE SWITCH number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Sor |
| Product | 1B4-K45-M4-C1A-PBTTCLA5 |
| Description | SOR PRESSURE SWITCH |
| Internal code | ONR1814780 |
| Weight | 4 |
| Technical specification | RANGE 35-275 BAR OVERRANGE 340 BAR PROOF 410 BAR ELECTRICAL RATING: 15 AMPS 250 VAC, 5 AMPS 30 VDC 1 = NO. 1 PISTON B4 = EXPLOSION PROOF/WEATHERTIGHT M20 X 1.5 (F) CONDUIT, ATEX EEX D IIC, NEMA 4X/IP66 K = SPDT, DEAD BAND FIXED 45 = NO. 45 SPRING M4 = 316L SS DIAPHRAGM/VITON O-RING C = 316/316LSST PROCESS CONNECTION 1A = 1/4 INCH NPT (F) PB = CARBON STL BODY/ STAINLESS STEEL ADJUST NUT TT = STAINLESS TAG PERMANENTLY ATTACHED TO HOUSING CL = ATEX FLAMEPROOF ENCLOSURE EEXD IIC T6 OR INTRINSICALLY SAFE EXIA IIC T6...T4 GB AS APPLICABLE A5 = CERTIFICATION OF: CALIBRATION COMPLIANCE/CONFORMANCE TYPICAL MATERIAL OF WETTED PARTS HYDROSTATIC PRESSURE TEST Weight/approx. 4 kgs/each |
