Please Contact Us to Order to offer competitive prices and delivery time for R.G.LAURENCE - 3315V788DCS GAS TURBINE VALVES number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | R.G.LAURENCE |
| Product | 3315V788DCS |
| Description | GAS TURBINE VALVES |
| Internal code | ONR473665 |
| Weight | 1 |
| Technical specification | GE P/N297A7267P002 SERIES 3300 – 3 Way Rotary Shaft Type 3/4" pipe size, Cv 1.8 3-way rotary shaft type solenoid valve with Rotary teflon shaft seal Flow form M - Supply normally closed De - energised to Vent Connect Supply @ A, Bleed Valves @ B, Exhaust @ C All type 304 Stainless Steel Valve Body and Inner Parts, Hard Chrome Plated Valve Discs Teflon Seals Class 300# screwed ends Vertical pipe mounting, upright solenoid FM approved Class 1, group D, division 1 explosion proof solenoid Enclosure with 1/2" NPT conduit connection 130 volts DC Continuous duty, class H insulated solenoid coil 4" long lead wires To handle air at a amximum opening differential pressure of 183 psi @550°F max. Current approx 10 Amps Inrush 0.15 Amps holding @130 volts DC |
