Please Contact Us to Order to offer competitive prices and delivery time for Baelz - 342-BK-SS-DN 100-PN 16-Kvs 130 three-way control valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Baelz |
| Product | 342-BK-SS-DN 100-PN 16-Kvs 130 |
| Description | three-way control valve |
| Internal code | ONR3184957 |
| Weight | 40.3 |
| Technical specification | 342-BK-SS without drive Case: GJS-400-18-LT - 5.3103 Internal parts: stainless steel Spindle sealing: stainless steel bellows and safety stuffing box Spindle diameter: 10 mm Nominal pressure: PN 16 Temperature/pressure: max. 350°C/11.2 bar - 50°C/16 bar Medium: thermal oils Through route: (A-AB) Kvso 0.004% Corner path: (B-AB) Kvso 2% Stroke: 22 mm DN 100, Kvs 130 max. permit differential pressure mixing valves (2 inputs/1 output) 2 bar Baelz 342-BK-SS-DN 100-PN 16-kvs 130 Best. - No. 342-062 Motor lift drive for variable mode Baelz 373-E07-20-18-S21... for installation on control valves up to DN 125 with thrust dependent motor limit switches Thrust: 2000 N Control speed Ty: 18 mm/min 50 Hz 21.7 mm/min 60 Hz Protection class: IP 42 Ambient conditions: max. 0... 50°C, 0... 75% r.F. with hand intervention Cover: plastic Stroke: max. 22 mm including aluminum stand (S21), coupling and mounting screws Power supply: 230 V, 50/60 Hz Weight: approx. 2.2 kg Baelz 373-E07-20-18-S21-230 Best. -No. 373-E07-20-18-301 |
