| BRAND | Scherzinger |
| Product | 351 FA/M075/GN/I39 |
| Internal code | ONR4053706 |
| Custom code | 84136039 |
| Technical specification | part nuber - 200960 Technical specifications • Direction of rotation: clockwise (cw), view of the pump shaft • Swallowing volume: 20.92 cm3 / rev • Connections: DIN ISO 228, G 3/4 " • Perm. Pump inlet pressure: -0.7 ... 0.5 bar • Operating temperature range: -15 to 160 ° C • Gears with increased backlash for better particle compatibility Construction materials • Housing material: EN GJL 250 • Gear material: EN 11SMn30 • Shafts: EN 11SMn30 • Plain bearings: EN GJL 250 • stat. Seals: FKM • Shaft seal: • double radial shaft seal • FKM • Pump adapter rotated 90 ° towards the terminal box Three-phase motor • Motor size: IEC80 • Motor bit: IMB34 • Flange diameter: 160mm • Nominal power: 0.75 kW • Nominal speed: 1,425 rpm • Voltage: l :: 230 / Y 400V, 50Hz, 3- • Protection class: IP 55 • Efficiency class: IE3 • Terminal box: right Important instructions • Please install a coarse filter with a 50 µm mesh size in front of the pump • Pump only suitable to a limited extent for media containing particles • Pump only suitable to a limited extent for media containing particles • The purity class of the medium should be at least 19/17/14 according to ISO 4406 |
