Please Contact Us to Order to offer competitive prices and delivery time for Scherzinger - 201455 - 4030-280-ZK-71-140 gear flange pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Scherzinger |
| Product | 201455 - 4030-280-ZK-71-140 |
| Description | gear flange pump |
| Internal code | ONR4505035 |
| Custom code | 84136039 |
| Technical specification | specifications • Preferred direction of rotation: left (ccw), view of the pump shaft • Intake volume: 2.8 cm³/U • Connections: DIN ISO 228, G 1/2" • Permitted Inlet pressure: -0.92... 88 bar • Permitted differential pressure: 12 bar (depending on viscosity) • Operating temperature range: -20... 130°C construction materials • Housing material: 1.4404 • Gear material: PEEK mod. • Shaft material: 1.4571 • Bearing material: PEEK mod. • Stat. Seal material: PTFE • Shaft seal: magnetic coupling, max.2 Nm Sm2Co17 magnets, encapsulated in 1.4404 For mounting on an IEC motor • Includes motor-side magnetic coupling bell • Standard: IEC 72-1 • Engine size: 71 • Engine design: IMB34 • Flange diameter: 140 mm • Motor shaft: 14x30 Please note • Pump not suitable for particulate media • According to ISO 4406, the purity class should be at least 19/17/14 • Please install a 50μm mesh size coarse-filter in front of the pump • Pump not suitable for liquids with magnetic particles |
