Discover the superior quality and performance of the Leser 4412.4822 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 4412.4822 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 4412.4822 :
At Onrion LLC , we offer the 4412.4822 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 4412.4822 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Leser products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 4412.4822 by Leser in United States?
You can purchase 4412.4822 by Leser from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the 4412.4822?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Leser in United States?
While we are not the official distributor or seller of Leser in United States, we source our products from reliable channels and offer you original Leser equipment at competitive prices.
How can I access 4412.4822 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 4412.4822 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 4412.4822?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
BRAND | Leser |
Product | 4412.4822 |
Description | SAFETY VALVE |
Internal code | ONR5019011 |
Technical specification | High performance conventional version 101 Item Number 10 Back To Summary Customer Reference 102 Tag number reader order code link K7TM33MB1K4XH03K3FP2AJ36X00L39H89H79H22L8JL64L49H01 X Operational conditions 201 medium - aggregate state - 202 Response pressure 24.20 bar-g CDTP 24.20 bar-g 203 min. external backpressure - operating temperature 20 °C 204 Maximum external backpressure - self-backpressure - xValve data 301 Item number 4412.4822 Ventilation H2 cap, screwed 302 Valve type Conventional design Standard dimensions (a, b, h) 124mm, 121mm, 436 mm 303 d⁴ 29.0 mm Weight 16.4 kg 304 flow cross section 660.5 mm² Outflow rate (D/G) ASME | PED 0.699 | 0.700 standard 305 Orifice according to API 520 not available Outflow rate (F) ASME | PED 0.521 | 0.450 standard 306 NPS 1 1/2 NPS 2 307 outlet CL 300 ASME B16.5 outlet CL 150 ASME B16.5 port 308 RF - SerSpiral fin, Ra=3.2-6.3 RF - SerSpiral fin, Ra=3.2-6.3 309 Case material 1.0619/SA-216 WCB/WCC - CS Seat bush/ seat Material 1.4404/316L - SS 310 Spring cover material 0.7043/GGG 40.3 - CS plate material 1.4122 - SS, hardened 311 Spring material EN 10270-2-FDSiCr 312 Spring pressure range min. [bar-g] 22.51 Spring pressure range max. [bar-g] 30,01 symbolic representation XOpt. 501 coloring: P2A RAL 5005, LESER blue (LID 1608.03) gross 0.00 EUR Documentation 801 Material quality certificate for: H01 housing — position 1 with material quality certificate 3.1 in accordance with DIN EN 10204 net 81,00 EUR 802 Documentation: H03 LESER CGA Certificate for Global Application Acceptance test certificate 3.1 in accordance with DIN EN 10204 net 40.00 EUR 803 Approvals: M33 Proof of testing the set pressure (TRB 513 4.2, TRD 504 3.3.4): EN 10204-3.2 (TÜV-Nord) |
