Please Contact Us to Order to offer competitive prices and delivery time for Badger Meter - 56500-163-2F66 flow meter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Badger Meter |
Product | 56500-163-2F66 |
Description | flow meter |
Internal code | ONR4192038 |
Custom code | 90261081 |
Technical specification | 167631 Type Vision 2008 2F66 0.5 - 7.5 l/min Trogamid with DIN devices outlet Vision 2008 2F66-DIN 565-163-2F66 turbine measuring mechanism type Vision 2008 2F66 with Power socket Materials and technical data: Case: Trogamid Rotor: PA12 Ferrite Bearing: PTFE/graphite Measuring range: 0.5 - 7.5 l/min Measurement accuracy: +/- 3% of measured value Impulse tap: Hall generator p-max: 25 bar t-max: 100 °C Connections: G 3/8" El. Connection: pin plate with 3 flat connectors (2.8x0.5) and DIN plug, EN60529 Installation length: 55 mm Installation position: Any K-factor: 4700 pulses/litre Power supply: 5-24 VDC |
