Please Contact Us to Order to offer competitive prices and delivery time for Stahl - 6109/111-0101-160-0111-31-4850-001 compact lamp number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Stahl |
| Product | 6109/111-0101-160-0111-31-4850-001 |
| Description | compact lamp |
| Internal code | ONR4954169 |
| Custom code | 94051140 |
| Technical specification | 287813 Emergency lamp with battery explosion-proof Type: 6109/111-0101-160-0111-31-4850-001 Version: with diffuser 2 x 40° Case material: Duroplast Silicone-free: or influence on paint wetting Dimensions (L x W x H): 440 mm x 185 mm x 90 mm AC operating voltage: 100... 240 V Operating time: 1.5/3h emergency light operation Battery version: NiCd battery, gas-tight Battery capacity: 2.2 Ah Battery operating voltage: 6 V Range of use (zones): 1, 2, 21, 22 Gas explosion protection: II 2 G Ex db eb ib op is IIC T4 Gb Dust explosion protection: II 2 D Ex tb op is IIIC T100 °C Db Min. ambient temperature: -30°C Max. ambient temperature: +50°C Protection class IP (IEC 60598): IP66/IP67 Through-wiring: clean/out wiring Terminal block installed: PE + N + L1 + L2 + L3 + L' Max. solid wire connection: 6 mm2 Flexible connection max.: 4 mm2 Control interface: without Holes: 3 x M25 Accessories: included Cable and cable entries: 2 x M25 Ø 7 — 17 mm Sealing plug: 2 x M25 x 1.5 Sealing plug material: black polyamide Scope (Conf) ATEX/IECEx Standard language Model size 1 Standard lamp design Area of application zone 1, 2, 21, 22 Bus system without DALI Address module without ADR Ballast 6046/311-841-060 NLE Standard Switch with Phoenix terminal block installed Number of terminals 6 Terminal description PE + N + L1 + L2 + L3 + L' Standard EXL9330+163R bath material Housing color similar to RAL 7035 Ex version Yes Packaging Individual packaging Light distribution with diffuser (2x40°) Light color 850 - 5000 K CRI80 Standard screw connection Yes Threaded plate connection side insert molding material plate (M25) Thread plate opposite side metal nut ungrounded (M25) Hole 1 opposite side none Hole 2 Connection side Hole open Hole 3 Connection side Hole open Hole 4 Opposite side hole open Pictogram front without Pictogram backside without Battery version with NiCd 2.2 (2.5) Ah battery Emergency lighting operating time test with 6046/... -.. 1-... Standard steel customer specification special standard versions |
