Please Contact Us to Order to offer competitive prices and delivery time for Stahl - 209263 / 6149/2-5211-5010 LED inspection light explosion-proof number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Stahl |
| Product | 209263 / 6149/2-5211-5010 |
| Description | LED inspection light explosion-proof |
| Internal code | ONR146433 |
| Weight | 1.4 |
| Custom code | 94054039 |
| Technical specification | Design: standard version Color rendering: >= 80 Color temperature: 5,000 K height: 52 mm Construction width: 52 mm Length: 595 mm Case material: aluminum Lamp power: 16 W Diffuser: with diffuser Luminous flux: 1,000 lm Luminaire efficiency: 63 lm/W Tube material: polycarbonate Protection class: II (protective insulation) Number of lamps: 1 diameter: 52 Fittings: 1 CMP-20s-A2F cable entry. Holes: - Connection cable fine-wired max.: 1.50 mm2 Light source: LED double row Rated current: 0.130 A Rated operating voltage AC: 110.00 - 240.00 V Frequency range: 50 - 60 Hz Rated operating voltage DC: 110.00 - 240.00 V Application area (zones): 1, 2, 21, 22 Gas explosion protection: II 2 G Ex d IIC T4 Gb Dust explosion protection: II 2 D Ex tb IIIC T100 °C Db Ambient temperature min.: -30 °C Ambient temperature max.: +60 °C Cable length: 5 m Type of connection cable: H07RN-F 2x1.5 qmm Protection class (IP): IP66/IP67 Protection class IP (IEC 60598): - |
