Please Contact Us to Order to offer competitive prices and delivery time for Bourns - 6534S-1-502 Potentiometer number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Bourns |
| Product | 6534S-1-502 |
| Description | Potentiometer |
| Internal code | ONR536217 |
| Weight | 0.02 |
| Technical specification | Electrical Characteristics1 Standard Resistance Range1 K to 100 K ohms Total Resistance Tolerance ±10 % Independent Linearity±0.5 % Effective Electrical Angle 320 ° ±3 ° End Voltage 0.1 % maximum (0.25 at 2 K ohms, 0.4 % at 1 K ohm) Output Smoothness 0.1 % Dielectric Withstanding Voltage (MIL-STD-202, Method 301) Sea Level 750 VAC minimum Power Rating (Voltage Limited By Power Dissipation or 350 VAC, Whichever is Less) +70 °C 1 watt +125 °C .0 watt Insulation Resistance (500 VDC)1,000 megohms minimum Resolution Essentially infi nite |
