Please Contact Us to Order to offer competitive prices and delivery time for ARCA - 6H3-P1 ECOTROL-W4 single seat control valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | ARCA |
| Product | 6H3-P1 ECOTROL-W4 |
| Description | single seat control valve |
| Internal code | ONR4796709 |
| Technical specification | DN25 PN160 (=PN100) cover flange with cooling fins Connection on both sides: Form B2 Installation length: 230 mm Case material: 1.4408 Material cone: 1.4571 Seat material: 1.4571 1-stage parabolic cone, kvs 6.3 curve =% seat Ø 20 mm, Class IV leakage Package: Latty 6118/ETF Fig.01, DP = 5 bar Type 812 MFI-20.3-OE Pneumat. 20mm stroke control drive Function: air opens, spring force closes Membrane area: 320cm² 3 springs adjustment range 0.75-1.5 bar Ausf. B pipe reversible air flow M14 connection thread, socket Ø 48 mm Operating pressure: 2.5 # max. 6 bar Material certificate EN 10204 3.1 (ARCA AS 01) Approval EN 10204 3.1 (ARCA AS 01) Interpretation in accordance with PED2014/68/EU |
