Please Contact Us to Order to offer competitive prices and delivery time for Flux (Sondermann) - 70-000068 - MA-PFSK-12/190-0,55/35 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Flux (Sondermann) |
| Product | 70-000068 - MA-PFSK-12/190-0,55/35 |
| Internal code | ONR4820477 |
| Custom code | 8413 70 51 |
| Technical specification | MAGSON BG4 magnetic centrifugal pump MA-PFSK-12/190-0.55/35 materials: Pump housing: PP (glass fiber reinforced) Impeller magnet unit: PP (glass fiber reinforced) Magnetic coating: PP (without glass fiber) O-ring: FKM Case thrust washers: oxide ceramic Impeller thrust plate: PTFE (carbon fiber reinforced) Plain bearing: SiC with ETFE mount Centering axis: oxide ceramic Connections: Suction side: G 2 ¼” * thread : Pressure side: G 2 ¼” * thread Delivery height: max. 12 m Flow rate: max. 190 l/min motor: rotary current, 230/400V, 550W, : 2900 min.-1, 50 Hz, : IN B5, IP55 FU suitability: yes, 3 cold conductors (PTC) Paint: RAL 5011 *) Threaded connection can optionally be used against loose flange DN40 can be replaced, please use accessories 70-001393 |
