Please Contact Us to Order to offer competitive prices and delivery time for Stahl - 8146/5-V37-305-51-1010-K safety switch 40 A explosion proof number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Stahl |
| Product | 8146/5-V37-305-51-1010-K |
| Description | safety switch 40 A explosion proof |
| Internal code | ONR4287971 |
| Custom code | 85371098 |
| Technical specification | AC rated operating voltage: 690 V Rated operating current: 40 A Case material: polyester resin glass fiber reinforced Detailed number of pins: 3 pin auxiliary contact opener: 1 opener Auxiliary contact Normally open: 1 N/lagging Additional clamp: standard (without) Area of application (zones): 1, 2, 21, 22 Gas explosion proof: II 2 G Ex db eb IIC T6 Gb Dust explosion protection: II 2 D Ex tb IIIC T80°C Db Min ambient temperature ፦40 °C ambient temperature max.: +48 °C special conditions for extended ambient temperature, see operating instructions: Extended ambient temp. min ፦40 °C Extended ambient temp max.: +66°C Protection class (IP): IP66 Cable entry: 2 x M40 Ø 12... 28 mm 1 x M20 Ø 4... 13 mm Connection cross-section: 10... 25 mm2 HIKO connection cross-section: 0.75... 2.5 mm2 fine-stranded |
