Please Contact Us to Order to offer competitive prices and delivery time for Stahl - Nr. 150494 Type 8570/11-506 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Stahl |
| Product | Nr. 150494 Type 8570/11-506 |
| Internal code | ONR4821452 |
| Custom code | 85366990 |
| Technical specification | 16 A wall socket explosion-proof Rated operating voltage: 200/346... 240/415 V AC Frequency range: 50/60 Hz Detailed number of poles: 3 P + N + PE Code color: red Coding (time setting): 6 Housing material: polyamide, reinforced with glass fiber Silicone-free: Yes Application range (zones): 1,2,21,22 Scope: European Union (ATEX) Gas explosion protection: II 2 G Ex db eb IIC T6 Gb Dust explosion protection: II 2 D Ex tb IIIC T80 °C Db Ambient temperature min.: -30 °C Ambient temperature max.: +55 °C Rated operation current: 16 A Rated operating current2:16 A Ambient temperature min. F: -22 °F Ambient temperature max. F: +131 °F Protection class IP (IEC 60529): IP66 Protection class IP (IEC 60079): IP66 Impact resistance (IEC 60079): 7.00 J Impact resistance (IEC 62262): IK10 Introduction 1: M25 x 1.5 Introduction 1 Type: Polyamide cable fitting Introduction 1 type: 8161/7-M25-1707 Introduction of 1 clamp: 7 - 17 mm Introduction 2: M25 x 1.5 Introduction 2 type: Polyamide sealing plug Introduction 2 Type: 8290/3-M25 |
