Please Contact Us to Order to offer competitive prices and delivery time for Sofima Filtri - AMD 151-FD-1-B-B-4-U0-XX Filter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Sofima Filtri |
| Product | AMD 151-FD-1-B-B-4-U0-XX |
| Description | Filter |
| Internal code | ONR4836460 |
| Custom code | 84212300 |
| Technical specification | AMD151010 AMD 151-FD-1-B-B-4-U0-XX FPE A1-B-06-B-N-FC-U0-XX UFI FPE A1 - SOFIMA AMD 151 SPIN-ON filter FPE - AMD = Max. operating pressure: 1.2 MPa (12 bar) Max. test pressure: 1.5 MPa (15 bar) Burst pressure: 2.5 MPa (25 bar) fatigue test 0 - 1.2 MPa (0 - 12 bar)/ 100000 cycles head: aluminum Filter element: steel By-pass valve: on request Operating temperature: -25° - +110° C A1 - 151 = type FC - FD= 12µ inorganic fibers - 12 µm [c] N - 1= NBR seals Buna B= with bypass 170 kPa (1.7 bar) B= threaded connection (BSP) 06 - 4= G 3/4" U0= opt. Differential pressure indicator 1.3 bar (130 bar) |
