Please Contact Us to Order to offer competitive prices and delivery time for Steimel - ASF3/50RD-123435R pump unit number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Steimel |
| Product | ASF3/50RD-123435R |
| Description | pump unit |
| Internal code | ONR4670466 |
| Custom code | 84136039 |
| Technical specification | A-SF3/50RD-VLFM, pump unit, 2-18 bar 4.0 kW, 1800, 460V star, 60Hz, IP55, Iso.F, B5, IE3 Gear pump unit: SF 3/50 RD - VLFM Product no.: ASF3/50RD-123435R Dimension sheet: DPA053D-112LFM-R31 Spare part list: DET053050RD-165R Suction and pressure connection: SAE 1 1/2 Case parts: EN-GJL-250 (GG-25) Sprocket shafts, noise opti.: 16MnCrS5, egh., helical gears Storage: multi-layer Shaft seal: radial shaft seal Elastomers: FKM Conveying medium: lubricating oil Viscosity: 50-5000 cSt Temperature: 10-60°C Flow rate: approx. 70.8/84.9 l/min Pressure: 5 bar Speed: 1450/1740 rpm Pressure relief valve Adjustment range: 2-18 bar Opening pressure: 8 bar Rotation direction: right Test run: yes, with HLPD 46 Coupling: BKUA055-1928-301 Pump support with base: BLF053250128LA21 Three-phase motor: LDM112-04-027 (BB) Engine data: Power: 4.0 kW Speed: 1800 rpm Voltage: 460 volt star Frequency: 60 Hz Efficiency class: IE3 Protection class: IP 55 Insulation class: F Type: B 5 Aggregate paint: primed HDO058 green Type plate: ETY924-D-E—PE02 |
