Please Contact Us to Order to offer competitive prices and delivery time for Steimel - ASF4/80RD-112340R pump unit number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Steimel |
| Product | ASF4/80RD-112340R |
| Description | pump unit |
| Internal code | ONR549666 |
| Weight | 1 |
| Technical specification | A-SF4 / 80RD-VLFM, 2-16 bar 3,0 kW, 1000, 230 / 400V, 50Hz, IP55, Iso.F, B5, IE2 Material number: 000,000,681,682 Gear pump unit: SF 4/80 RD - VLFM Article No. : ASF4 / 80RD-112340R Dimension sheet: DPA054D-132LFM-R31 Spare Parts List: DET054080RD - 165 . Suction and pressure connection: SAE 2 Housing components: EN-GJL-250 (GG-25) Waves: 16 Mn Cr S5, EGH. Gears: EN-GJS-400-15 (GGG-40) ionitrided, helical teeth Toothing: noise-optimized Storage: multilayer MD Shaft seal: radial shaft seal Elastomers: FKM Medium: Oil Viscosity: 50 to 5000 cSt. Temperature: 10 - 60 ° C Flow rate: approximately 68/82 l / min. Pressure: 5 bar Speed: 1000/1200 1 / min. Pressure relief valve Opening pressure: 8 bar Setting range: 2 - 16 bar Direction of rotation: right Test run: Yes, with HLPD 46 Clutch: BKUA065-2438-301 Bellhousing with Foot: BLF054300168LA21 Three-phase motor: LDM132-06-006 (Birkenbeul) Motor data: Performance 1/2: 3,0 / 3,4 kW 1/2 rpm: 1000/1200 1 / min. Voltage / Frequency 1: 230/400 volts at 50Hz Voltage / frequency 2: 265/460 volts at 60Hz Efficiency: IE2 with additional plate (without IE2) for Voltage: 220-240 / 380-420 V at 50/60 Hz 250-280 / 440-480 V at 60 Hz Protection: IP 55 Insulation class: F Type: B 5 Finish: Primed HDO058, green Nameplate: ETY924-D-E - PE02 |
