Please Contact Us to Order to offer competitive prices and delivery time for Afriso - DMU 21 D (33410-1-01-153-01-1) Pressure transmitter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Afriso |
| Product | DMU 21 D (33410-1-01-153-01-1) |
| Description | Pressure transmitter |
| Internal code | ONR4676961 |
| Custom code | 90262020 |
| Technical specification | Pressure transmitter for differential pressure measurement with on-site display. Display: 4-digit, red 7-segment display digit height 7 mm, -1999/+9999 Measuring principle: 2 piezoressistive stainless steel measuring cells Adjustment options: Turn-down 1:10 digital attenuation 0.3/30s Display housing can be rotated by 330° Supply voltage: DC 24V ± 10% Analog output: 4 - 20 mA/3-wire Switch output: 1 x open collector (PNP), max. 125 mA Switch-on and switch-off delay: 0 to 100 s, adjustable Operating temperature range: medium -40/+125°C Ambient -25/+85°C Storage -40/+85°C Housing: plastic (PA 6.6, polycarbonate) Electrical connection: plug M12 x 1, 5-pin Parts in contact with medium: 316L stainless steel, FKM Process connection: 2 x G ½B (DIN 3852) Can be rotated by 300° each Measuring range: 0/20 bar Maximum static pressure, single-sided: 1 x FS Accuracy:? ± 1% BFSL (IEC 60770) Protection class: IP 65 (EN 60529) |
