Please Contact Us to Order to offer competitive prices and delivery time for POMPE CUCCHI SRL - FMG015WECDNE020 Gear pump with motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | POMPE CUCCHI SRL |
| Product | FMG015WECDNE020 |
| Description | Gear pump with motor |
| Internal code | ONR4481279 |
| Custom code | 84136020 |
| Technical specification | 0.55 kW 4-pole 440/3/60 IP54 B3/B14 G25 cast iron body and cover CERAMIC/GRAPHITE/FPM mechanical seal Built-in brass/carbon steel bypass valve 18 NCD5 hardened carbon steel shafts and C45 steel gears DU Sintered Support Bushings Lantern not present (monoblock pump) Anticlockwise direction of rotation (viewed from the motor side) Motor power 0.55 kW 4-pole 440/3/60 IP54 B3/B14 Capacity 18 Lt/min @1750 RPM Suction pressure 0 BAR Delivery pressure 10 BAR Differential pressure 10 BAR Horizontal mouth orientation 3/4" BSP connections Rotation speed 1,750 RPM @50 Hz Paint pump red RAL 3003 > >>>>>>>>>>>>>>>>>>>>>>>>>>>>> PUMP SAME AS THE OLD TYPE FMG15/WEC0B00 - S/N 65876 |
