Please Contact Us to Order to offer competitive prices and delivery time for FSG Fernsteuergeräte - 1896Z10-009.002 Cable travel switch with voltage output number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | FSG Fernsteuergeräte |
| Product | 1896Z10-009.002 |
| Description | Cable travel switch with voltage output |
| Internal code | ONR4480535 |
| Custom code | 90318020 |
| Technical specification | G015-PK620D-R/U-2SEN/E0/GS120 in aluminum housing protection class IP 65 electr. Connection via plug-in device with mating connector Housing 120 mm Ý installation depth 130 mm Double ball bearing drive shaft 12h7 Ý free wavelength 30mm shaft with feather key according to DIN with 3 flange-side thread holes M6 12mm deep N/Zg. 1896 Z 10 with low-backlash adjustment gear 20:1 slow with plastic potentiometer PK620d/MU-U01 1574Z05-001.003 with integrated R/U converter for output 0-10V at RA min 500Û with counterclockwise rotation of the drive shaft 20-30VDC power 4-wire circuit with galv. separation between supply and output with a built-in forced separate cam limit switch switching point position by means of screw adjustable turner with motorized grinder and Switch reset within from 30 to 40 sec (direction 0 V) |
