Please Contact Us to Order to offer competitive prices and delivery time for Settima - GR25 SMT 16B 30L RP T1 V screw pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Settima |
| Product | GR25 SMT 16B 30L RP T1 V |
| Description | screw pump |
| Internal code | ONR4888893 |
| Technical specification | Q/P (1450 rpm; 46 mm²/s; 30 bar) =14.47 l/min/1.18 kW, NPSH = 1.96 mWS Q/P (1450 rpm; 257.6 mm²/s; 30 bar) =15.04 l/min/1.35 kW, NPSH = 2.46 mWS GR25 = frame size SMT 16B = pressure level 40 bar 30L = nominal flow with cylindrical shaft ø19mm for installation with pump carrier and coupling aluminum housing RP = externally adjustable pressure relief valve 5-25 bar Pressure connection G1/2 T1 = RP suction housing G3/4, mounted in the T1 layer V = Viton sealing material |
