Please Contact Us to Order to offer competitive prices and delivery time for Settima - GR32 SMT 16B 55L S2 RP T4 screw pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Settima |
| Product | GR32 SMT 16B 55L S2 RP T4 |
| Description | screw pump |
| Internal code | ONR4902962 |
| Custom code | 84136070 |
| Technical specification | Q/P (1450 rpm; 46 mm²/s; 30 bar) =22.75 l/min/1.83 kW, NPSH = 1.94 mWS Q/P (1450 rpm; 257.6 mm²/s; 30 bar) =23.65 l/min/2.05 kW, NPSH = 2.44 mWS GR32 = frame size SMT 16B = pressure level 40 bar 55L = nominal flow with ø19mm cylindrical shaft for installation with pump carrier and coupling aluminum housing S2 = option for high viscosities (250-500 cSt), poor efficiency RP = externally adjustable pressure relief valve 5-25 bar SAE pressure port 1 3000psi T4 = RP suction housing with SAE connection 11/4 3000psi, mounted in position T4 NBR sealing material |
