Please Contact Us to Order to offer competitive prices and delivery time for Settima - GR32-SMT16B-75L Pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Settima |
| Product | GR32-SMT16B-75L |
| Description | Pump |
| Internal code | ONR293775 |
| Weight | 1 |
| Custom code | 84136070 |
| Technical specification | screw pump GR32 SMT 16B 75L Q/P (1450 rpm; 46mm²/s; 10 bar) =36.86l/min/0.98kW, NPSH=2.1mWS Q/P (1450 rpm; 257.6mm²/s; 10 bar) =37.59l/min/1.25kW, nPSH=2.64mWS GR32 = frame size SMT 16B = pressure level 40 bar 75L = nominal flow rate with ø19mm cylindrical shaft for mounting with pump carrier and coupling aluminum housing SAE pressure connection 1 3000psi Standard suction housing with SAE connection 11/4 3000psi NBR sealing material |
