Please Contact Us to Order to offer competitive prices and delivery time for Settima - GR32-SMT16B-35L AC24 B5 G HD V Screw pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Settima |
| Product | GR32-SMT16B-35L AC24 B5 G HD V |
| Description | Screw pump |
| Internal code | ONR4696068 |
| Technical specification | SMT16B screw pump for industrial applications with shaft seal, low pressure Mounting flanges flanges ISO 3019/2 according to ICE standard for option AC-direct mounting Pipe connections SAE 3000PSI and BSP srew threads Mounting position in any order, SMIT complete or suction-sited in oil drive to be exempt from axial and radial shaft stresses rotation clockwise ,from shaft’s view revolution speed 500 to 3600 rev/min (special mediums, air, high viscosity after consulting) sizes 20 25 32 40 45 55 60 70 80 90* 110* Rate of deliveries 8 - 3400 l/min (2750 rev/min 2 pol.) pressures pcont.=40 bar, ppeek=50 bar, (special mediums, air, hight viscosity after consulting) inlet pressures min. 0,7 bar absolute, max 3 bar / *GR90+GR110 2pol operation 0.5 - 3 bar inlet pressure service mediums HLP oil according to DIN 51524 part 1+2 biodegradable mediums HETG+HEPTG*HEE synthesized fluids and emulsions HFA water-oil-emulsions min. 5% oil contingent HFB water-oil-emulsions 50% oil contingent HFC water glycol, water contingent max. 35 - 55% HFD phosphaticaly ester Lubrication oils with hight viscosity , cavitation or air contingent synthesized fluids MIL-H, Skydrol All these fluids require a close technical examination and could modify the promised technical proberties viscosity 4 - 2000 mm2 /s (attend options S1-S4 + SN) seals standard viton option NBR, FPM, EPDM noise 52 - 68 dba (2750 rev/min hydraulic oil) body material standard alu, option anodic oxide, caste iron, carbon steel 18NiCrMo5 srews C25 steel for the main screw, caste iron for the lateral screws, option nitrided or case hardened shafts temperature -20 bis +60 °C ambient temperature -20 bis +180°C medium temperature dependent on the seals material! filtration recommmended on NAS1638 class 10 or ISO 4406-19/16 filtration 25>= 75 maintenance none |
