Please Contact Us to Order to offer competitive prices and delivery time for Settima - GR40-SMT16B-150L AC28 B5 RF2 Pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Settima |
| Product | GR40-SMT16B-150L AC28 B5 RF2 |
| Description | Pump |
| Internal code | ONR3710574 |
| Weight | 10 |
| Custom code | 84136070 |
| Technical specification | Q/P (1450 rpm; 46mm²/s; 10 bar) =71.98l/min/1.86kW, nPSH=2.27mWS Q/P (1450 rpm; 257.6mm²/s; 10 bar) =73.43l/min/2.32kW, nPSH=2.88mWS Settima item number: TB150LA28B5RF2 Pump weight: 7kg Country of origin: Italy, customs tariff number: 84136070 GR40 = frame size SMT 16B = pressure level 40 bar 150L = nominal flow AC28/B5 = Direct attachment to electric motor type /B5 (ø250) aluminum housing RF2 = internal fixed pressure relief valve (10 bar) SAE pressure connection 11/4 3000psi Standard suction housing with SAE connection 11/2 3000psi NBR sealing material |
