Please Contact Us to Order to offer competitive prices and delivery time for Settima - GR40 SMT 16B 150L AC28/B5 S2 RF3 PUMP number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Settima |
| Product | GR40 SMT 16B 150L AC28/B5 S2 RF3 |
| Description | PUMP |
| Internal code | ONR4866738 |
| Custom code | 84136070 |
| Technical specification | Q/P (1450 rpm; 46mm²/s; 15 bar) =68.78l/min/2.57kW, NPSH=2.27mWS Q/P (1450 rpm; 257.6mm²/s; 15 bar) =70.55l/min/3.05kW, nPSH=2.88mWS Settima Product number: TB150LA28B5S2 (250-500 cSt) RF3 GR40 = frame size SMT 16B = pressure level 40 bar 150L = nominal flow AC28/B5 = Direct attachment to electric motor type /B5 (ø250) aluminum housing S2 = option for high viscosities (250-500 cSt), poor efficiency RF3 = internal fixed pressure relief valve (15 bar) SAE pressure connection 11/4 3000psi Standard suction housing with SAE connection 11/2 3000psi NBR sealing material |
