Please Contact Us to Order to offer competitive prices and delivery time for Settima - GR55 SMT16B 250L AC28 B5 RF1 screw pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Settima |
| Product | GR55 SMT16B 250L AC28 B5 RF1 |
| Description | screw pump |
| Internal code | ONR4875474 |
| Technical specification | Q/P (1450 rpm; 46mm²/s; 5bar) =135.54l/min/1.94kW, NPSH=2.23mWS Q/P (1450 rpm; 257.6 mm²/s; 5 bar) =137.33l/min/2.63kW, NPSH=2.82mWS Weight of the pump: 15.5kg Country of origin: Italy, customs tariff number: 84136070 GR55 = frame size SMT 16B = pressure level 40 bar 250L = nominal flow AC28/B5 = direct attachment to electric motor module /B5 (ø250) aluminum housing RF1 = internal fixed pressure relief valve (5 bar) SAE pressure port 2 3000psi Standard suction housing with SAE connection 21/2 3000psi NBR sealing material |
