Please Contact Us to Order to offer competitive prices and delivery time for W+S - IH581.120ZR63.02048.STC1 Incremental encoder number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | W+S |
| Product | IH581.120ZR63.02048.STC1 |
| Description | Incremental encoder |
| Internal code | ONR4172075 |
| Technical specification | Incremental encoder hollow shaft * Construction size: 58 mm * Hollow shaft: 12 H7 mm * Mech. Opt .: torque arm mounted on the front at 12 o'clock * Connection: special * Connection type: radial * Output signals: A + B + Z + A \ + B \ + Z \ * Output: push-pull * Supply voltage: 4.75 to 30 VDC * Pulses / revolution: 2048 Special version STC1: * Special connector Coninvers RC-12P1N112G400 (1.14.0120) and mating connector standard (1.13.0101) directly on the 0.5 m cable assembled * Mounting Clip DR58-TC01 (2.69.0801) * 100 ° working temperature * Pin assignment as with S099 * Enclose an additional nameplate |
