Please Contact Us to Order to offer competitive prices and delivery time for Schmidt - IL 30.010 MPM (550251) AIRFLOW METER number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Schmidt |
| Product | IL 30.010 MPM (550251) |
| Description | AIRFLOW METER |
| Internal code | ONR4590929 |
| Technical specification | SCHMIDT volume flow sensor IL 30.010 MPM With factory calibration (no accredited calibration) Article No. 550251 Measurement method: multi-point measurement Installation connection: internal thread DN25 (G1) Measuring range: 0 ... 229 standard m³/h Analog output: current interface 4 - 20 mA Pulse output: high-side driver, pulse value 0.1 / 1.0 standard m³ Display: 4 duo LEDs Operating pressure: max. 16 bar (g) Operating voltage: 24 V DC +/-10% Main connection: M12, male, A-coded, 5-pin Module connection: M12, female, A-coded, 5-pin |
