Please Contact Us to Order to offer competitive prices and delivery time for Badger Meter - IOG BSP 3“ Alu 1.4571 Viton with PNP pulse generator number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Badger Meter |
| Product | IOG BSP 3“ Alu 1.4571 |
| Description | Viton with PNP pulse generator |
| Internal code | ONR4798806 |
| Custom code | 9028 20 00 |
| Technical specification | Oval wheel meter type Ind-og 3" BSP in aluminum with PNP pulse generator Materials and technical data: Measuring principle: oval wheel meter Housing & cover: aluminum Oval wheels: 1.4571 O-ring: Viton Measuring range: 20 - 700 l/min over 5 CPAs: viscosity : 38-700 l/min below 5 CPAs: viscosity Measurement accuracy: ± 0.5% of the measured value Viscosity range: up to 1000 mPas P-max: 25 bar t-max: -25 - + 70°C Installation length: approx. 180 mm Connection: internal thread R 3" BSP PNP sensor assembly with stainless steel adapter Function: PNP open collector Signal: unscaled pulse Supply: 5-30VDC Cable length: 3m |
