Please Contact Us to Order to offer competitive prices and delivery time for Bender - IR155-3204 / B91068139CV4 A-isometer card version number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Bender |
| Product | IR155-3204 / B91068139CV4 |
| Description | A-isometer card version |
| Internal code | ONR549023 |
| Weight | 1 |
| Custom code | 90303370 |
| Technical specification | B91068139CV4 DC 0... 1000 V A-isometer Board version Us = DC 10... 36 V Ri = 1200 kOhm Switching output: Device status highside Measured value output: PWM 5... 95% highside Ce max.: 1 μF Response value parameterizable: 100 kOhm... 1 Mohm Undervoltage detection Parameterizable: 0 V... 500 V Response time: <20 sec. Power On release: = 2 s Measuring method: DCP factor adjustable: 1... 10 Connectors: Tyco connector connection kit (B91068501) and mounting kit (B91068500) must be ordered separately! Lackened board surface. Please specify the setting params. in the order! Once upon a time Parameter & Limit O. Limit I Value Response value 100 kohms 1 Mohm I =? Not detected 0 V 500 V I =? F. mean DCP 1 10 I =? =========================================== 0.060 Position net weight: KGS 90303370 HS code: PREF=NO DE C/O: Instruments and apparatus for measuring or checking voltage, current or power, excluding a recording device (excl. multimeters), excl. Counter of item 9028 |
