Please Contact Us to Order to offer competitive prices and delivery time for Alre - JDL-112 (H5309100) Differential pressure switch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Alre |
| Product | JDL-112 (H5309100) |
| Description | Differential pressure switch |
| Internal code | ONR3811586 |
| Weight | 1.76 |
| Custom code | 90262080 |
| Technical specification | Differential pressure switch with mounting bracket, mechanical, 40... 600Pa, guard, housing dimensions: 76 x 63 x 93 mm. Rated surge voltage: 4000 V. Pressure connection: 6.2 mm. Electrical connection: screw terminals Casing colour: black. Function type: guard. Storage temperature: -15... +80 °C. Housing material: plastic. Max. pressure: 30000 Pa. Mounting/fixing: wall mounting Surface finish: matte. Control function: switches on in case of overpressure or underpressure. Protection class: IP 54. Protection class: II. Safety and EMC: in accordance with DIN EN 60730. Silicon-free. Ambient temperature up to: 80. Ambient temperature of: -15. Pollution level: II. Permissible humidity: max. 95% R.H., non-condensing. Medium temperature: -15... +80°C. Number of outputs: 2. Max. switching voltage: 230 VAC, 50 Hz24 VDC. max. switching current: 5 (1) AAC1 (0.2) ADC. Min. switching voltage: 12 VAC, 50 Hz12 VDC. Min. switching current: 1 mA. Floating free. Switching element: microswitch. Switching contact: changeover contact, gold contact. Breaking capacity: 1150 WAC, 24 WDC. Output signal: |
