Please Contact Us to Order to offer competitive prices and delivery time for Omega - LVU503 2” NPT Level Transmitter 9.8’ (3M) range, 4 SPST relays, w/ Fob USB Interface number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Omega |
| Product | LVU503 |
| Description | 2” NPT Level Transmitter 9.8’ (3M) range, 4 SPST relays, w/ Fob USB Interface |
| Internal code | ONR4903665 |
| Technical specification | Range: LVU501: 1.5” to 4.9’ (3.8 cm to 1.5 m), LVU503: 4” to 9.8’ (10.1 cm to 3 m) Accuracy: LVU501: 0.125” (3 mm), LVU503: ± 0.2% of range Resolution: LVU501: 0.019” (0.5 mm), LVU503: 0.039” (1 mm) Deadband: LVU501: 1.5” (3.8 cm), LVU503: 4” (10.1 cm) Beam width: 2” (5 cm) Configuration: WebCal® PC Windows® USB® 2.0 Memory: Non-volatile Supply voltage: 14-28 VDC Max. consumption: 0.5W Loop resistance: 500 ohms @ 24 VDC Signal output: 4-20 mA, two-wire Signal invert: 4-20 mA or 20-4 mA Signal fail-safe: 4 mA, 20 mA, 21 mA, 22 mA, hold last Contact type: (4) SPST relays Contact rating: 60 VA, 1A maximum Contact fail-safe: Open, closed, hold last Contact hysteresis: Selectable Process temp.: F: -40 to 176º, C: -40 to 80º Temp. comp.: Automatic Ambient temp.: F: -31 to 140º, C: -35 to 60º Pressure: 30 psi (2 bar) Enclosure rating: Type 6P (IP68) Encl. material: Polypropylene Transducer type: Reflective Ultrasonic Transducer mat.: Polyvinylidene fluoride Cable jacket mat.: Polyurethane Cable type: 9-conductor, shielded Cable length: 48” (1.2m) Process mount: 2” NPT, or 2” G Mount gasket: 2” G FKM® Classification: General purpose Approval: UL 61010-1 Compliance: CE, RoHS |
