Please Contact Us to Order to offer competitive prices and delivery time for FSG Fernsteuergeräte - 5875Z02-016.013 Intrinsically safe angle sensor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | FSG Fernsteuergeräte |
| Product | 5875Z02-016.013 |
| Description | Intrinsically safe angle sensor |
| Internal code | ONR3591782 |
| Weight | 0.6 |
| Custom code | 90318020 |
| Technical specification | 5875Z02-016.013 Intrinsically safe angle sensor Type: MH1023-mu/ex Transmitter with ATEX approval PTZ 17 ATEX 0001 and IECEx approval IECEx KIWA 17.0010/PTZ 18,0004 Temperature class T4 in the housing of synchronous size 23 Protection class IP 66 stainless steel flange and housing cap Angle measurement range max. 0 - 360° Resolution: 14bit/360° output: 4 - 20 mA max. load: (Us-8V)/20mA Output: 2-wire technology Active angle and direction of rotation across the back Programmable membrane keyboard Power supply: 8-26V DC Temperature range -30°C to +80°C electrical connection via shielded cable Length 7m shaft diameter 10 mm, Length 24 mm from support with shaft sealing ring ED103-0066 |
