Please Contact Us to Order to offer competitive prices and delivery time for Badger Meter - MID M 1000 mit Badger Flansch DN 32/16 Magnetic-inductive flowmeters number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Badger Meter |
| Product | MID M 1000 mit Badger Flansch DN 32/16 |
| Description | Magnetic-inductive flowmeters |
| Internal code | ONR3452074 |
| Weight | 25 |
| Custom code | 90261021 |
| Technical specification | MID 2-32/40f/ST-HG-ML/HC-ST M10DM magnetic inductive flowmeter Type ModMag M1000 Sensors: Type II Process connection: flange EN 1092-1/St 37 DN/PN: 32/16 *Measuring range: 1.4 - 579 l/min Installation length: 225 mm Lining: hard rubber max. temp.: 80 °C Electrodes: measuring and no-load electrodes electr. Material: Hastelloy C Housing: St. 37 painted grey Transmitter: type M1000 Assembly: assembled version Software language: English/German * Measurement units: Metric Current output: 0/4-20 mA * Final value scale: standard (2.5 m/s) Pulse output: active 24 V DC/passive * Pulse rate: standard (1 PPL) LCD display: 4-line Flow display: 8-digit (uni/bidirectional) 2 totalizers: 14 digits Degree of protection: IP 67 Auxiliary power: 9 - 36 VDC Min.conductivity: 5 micros/cm *Accuracy: +/- 0.3% of the measured value |
