Please Contact Us to Order to offer competitive prices and delivery time for Rsf Elektronik - MSA670 art no1298016-13 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Rsf Elektronik |
| Product | MSA670 art no1298016-13 |
| Internal code | ONR4897710 |
| Technical specification | Measuring length: 469 mm Accuracy class: ± 10.0 μm Division period: 20,000 μm Output signal: square wave signals, TTL level not clocked with 1-way interpolation Reference mark position: Distance-coded reference marks with a basic distance of 1000 x division period Sealing type: NBR sealing lip Voltage supply: 5 V (+-10%) Minimum flank spacing: 3,300 μs Fault signal: OT Reference pulse width: 90° Limit switch: without Connection direction: cable outlet right Cable length: 3.00 m Electrical connection: Sub-D plug, metallized plastic housing, 2-row, with Locking screws, pin, 15-pin Port configuration: D1143258 Cable type: PUR Ø 4.3 mm with protective hose Ø 7.3 mm |
