Please Contact Us to Order to offer competitive prices and delivery time for Itron - Meter type SL761 remote reading digital Counter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Itron |
| Product | Meter type SL761 |
| Description | remote reading digital Counter |
| Internal code | ONR541899 |
| Weight | 1 |
| Technical specification | Meter type SL761 Static 3-phase 4-wire meter for internal measurement of active, reactive and apparent power in each direction, and separately per phase; acc. IEC 61036 (active cl.1), IEC 60687 (active cl. 0,2S and cl. 0,5S) and IEC 61268 (reactive cl.2) • Total and per phase energy registers • Internal clock; back up via Super-Cap or battery • IR interface acc. IEC1107 • Electrical interface RS-232 • Protocoll standard acc. COSEM/DLMS; • ID system acc. OBIS • Operational logbook • Dimensions acc. DIN43859 • Operating temperature range –25 ºC to +55 ºC • Limited operation temperature range –40 ºC bis +70 ºC Tariffication and load profileTarifregister (Ressource Level 1) • Energy: 3 channels with 10 registers • Power: 3 channels with 7 registers • Load profile with 3 channels Inputs/Outputs (Light I/O) • 1 Control input • 2 Control outputs • 2 Pulse outputs • 2 Pulse inputs 3-Phase / 4- wire meter for current and voltage transformer connection • Nominal voltage 3 x 58/100 V • Nominal / rated current 5(10) A • cl. 0,5 (active); cl. 2,0 (reactive) |
