Please Contact Us to Order to offer competitive prices and delivery time for Ascon - QP-3311 program controller series QP number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Ascon |
| Product | QP-3311 |
| Description | program controller series QP |
| Internal code | ONR4493079 |
| Technical specification | supply voltage: 100... 240 Vac, 50/60 Hz serial interface: RS485 (jBus, ModBus protocol) Y6 continuous output: 0 (4)... 20mA or 0 (1)... (5) 10Vdc dimensions: 96 x 96 mm DIN, depth 150 mm programs - Number of programs: 16 - Segments/Program: 99 - max. number of segments: 255 Input (configurable): - Pt100 - thermocouples (L, J, T, K, S, R, B, N, W) or - Continuous signals linearly or with square root conversion 0 (4)... 20 mA, 0... (50) 200 mV, 0... 1 V, 1... 5 V, 0... 5 V or 0... 10 V Control behavior (configurable) - On/off hysteresis - heating or cooling characteristics, - heating/cooling characteristics - 3-point step (motor control, OPEN-NEUTRAL-CLOSE) output (configurable) - Logic, relay, or continuous (0 (4)... 20 mA, 1... 5V, 0... 5V or 0... 10V) additional output Y6: (0 (4)... 20 mA, 1... 5V, 0... 5V or 0... 10V) Protection class: front IP54 (IP65 optional) PID fuzzy algorithm with self-optimization and setpoint ramps - three configurable digital inputs - (ext. program start/stop/stop, keyboard lock, auto/man) 24 Vdc voltage output for ext. Transmitter options: - PC configuration tool |
