Please Contact Us to Order to offer competitive prices and delivery time for Banner Engineering - QS18VP6LLPQ-76914 QS18 SERIES ALL PURPOSE PHOTOELECTRIC SENSOR number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Banner Engineering |
| Product | QS18VP6LLPQ-76914 |
| Description | QS18 SERIES ALL PURPOSE PHOTOELECTRIC SENSOR |
| Internal code | ONR770885 |
| Weight | 1 |
| Technical specification | Cable Length (m) 2 Sensing Beam Visible Red Laser Power DC Sensing Mode (General) Retroreflective Sensing Mode (Detailed) Polarized Housing Style Rectangular w/M18 Mount Primary Housing Material ABS Laser Classification Class 1 Small Visible Spot Laser Input/Output Discrete Max Sensing Distance (mm) 10000 Outputs PNP Power Supply/Supply Voltage 10-30 V dc Connection Pigtail QD Quick Disconnect Type M8 Min Op. Temp. (°C) -10 Operation Light/Dark Operate Max Op. Temp. (°C) 50 Output response time (ms) 0.7 Sensing Beam Wavelength 650 Delay at Power-up (ms) 200 Repeatability (µs) 130 Number of Pins 4 IP Rating IP67 NEMA Rating NEMA 6 Max Op. Relative Humidity [%] 95% @ 50°C Lens Material Acrylic Adjustments Potentiometer Barrel Diameter (mm) 18 Indicator LEDs Feature: Timing (Hold/Delay) No Feature: Encapsulated No Feature: Hazardous Area No Feature: Audible No Feature: Chemical Resistant No Feature: Quick Disconnect Yes |
