Please Contact Us to Order to offer competitive prices and delivery time for Michael Riedel Transformatorenbau - REIA 100 isolating transformer number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Michael Riedel Transformatorenbau |
| Product | REIA 100 |
| Description | isolating transformer |
| Internal code | ONR4614187 |
| Technical specification | Primary voltage (PH-PH): AC 400/460 V Primary current: 0.25/0.22 A Secondary voltage (PH-PH): AC 24 V Secondary current: 4.17 A groupset: Ii0 Rated frequency: 50/60 Hz Protection class: SK I (protection class 1) Operating mode: S1 (continuous operation)/100% ED Ambient conditions: 40°C/E Cooling type: ON (normal air convection) Installation height: 1000m above sea level Degree of protection: IPXXB (finger-safe) Primary connection: terminals (screw connection) for 4 mm² Secondary connection: terminals (screw connection) for 4 mm² Earth connection: Faston for 6.3 mm Manufactured and tested according to: VDE 0570-2-6/EN61558-2-6 (safety transformer) Mechanical data: Dimensions (W x D x H): approx. 85 x 82 x 93 mm Mounting dimensions (W x D): 64 x 61 mm, for M4 |
