Please Contact Us to Order to offer competitive prices and delivery time for B-COMMAND - RX-LW0251-AFC-10024S Slip rings series RotarX number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | B-COMMAND |
| Product | RX-LW0251-AFC-10024S |
| Description | Slip rings series RotarX |
| Internal code | ONR4282364 |
| Technical specification | Hybrid Slip Rings Fiber Optic + Electrics Number of bushings: 25 (24 rings) ... of which fiber optics: 1 ... of which signal: 24 (24 rings) Fiber Optic Specifications: Connection: FC Single Mode Fibre types: 9/125μm Wavelength: 1310/1550 [nm] Insertion loss: 0.6dB Return loss: 55 dB Electrical Specifications Signal feedthroughs: Rated current: 2A per ring Max. working voltage: 380VAC/DC Cable Specification: AWG22 Teflon Dielectric Strength: 500VAC @50Hz Electric noise: max. 10MOhm Insulation resistance: 500MOhm @ 500VDC Cable length rotor: 300mm Stator cable length: 300mm Mechanical Specifications Case outer diameter: approx. 56 mm Case length: approx. 106.4 mm Contact material: gold-gold Case Material: Aluminium Rotation speed: 0-50 rpm. Working temperature ፦30°C to +80°C Degree of protection: IP51 Operating Humidity: 0~ 85% RH Service life: 50 million revolutions |
