Please Contact Us to Order to offer competitive prices and delivery time for Steimel - PSF3/32RD-123399R number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Steimel |
| Product | PSF3/32RD-123399R |
| Internal code | ONR4431145 |
| Technical specification | P-SF3/32RD-VLF, gear pump, 2-18 bar FKM, LF 250x128 according to VDMA for motors IEC 100 and 112 length 470,00 mm width 275 mm height 280 mm Siemens AG Material number: 000.001.156.495 Gear pump: SF 3/32 RD - VLF Item no.: PSF3/32RD-123399R Dimension sheet: DPA053D-100LFM-R31 Spare part list: DET053032RD-165R Suction & pressure connection: SAE 1 ½ Case parts: EN-GJL-250 (GG-25) Pinion shafts: 16mnCrS5, egh., helical gearing noise-optimized Shaft seal: radial shaft seal elastomers: FKM Storage: multilayer Fluid: lubricating oil Viscosity: 50-5000 cSt. temperature: 10-60°C Flow rate: approx. 50.1 l/min. pressure: 5 bar Rotation speed: 1450 rpm pressure relief valve Adjustment range: 2-18 bar Opening pressure: 8 bar Rotation direction: right Trial run: yes, with HLPD 46 Clutch: BKUA055-1928-301 Pump rack: BLF053250128LA21 suitable for: 3-phase standard motor: IEC 100 and 112 Design: B 5 Aggregate paint: without Nameplate: ETY924-D/E—PE01 Engine mounting screws: 4 pieces, IBO12X030VZ |
