Please Contact Us to Order to offer competitive prices and delivery time for Steimel - ASF4-63RD-170928R A-SF4/63RD-VLFM, pump unit, 2-16 bar number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Steimel |
| Product | ASF4-63RD-170928R |
| Description | A-SF4/63RD-VLFM, pump unit, 2-16 bar |
| Internal code | ONR4035713 |
| Technical specification | Gear pump unit: SF 4/63 RD - VLFM Product no.: ASF4-63RD-170928R Dimension sheet: DPA054D-112LFM-R31 Spare part list: DET054063RD--165R Suction and pressure connection: SAE 2 Case parts: EN-GJL-250 (GG-25) Shafts: 16 Mn Cr S 5, hardened gears, noiseless: EN-GJS-400-15 (GGG-40), helically toothed and nitrided Shaft seal: radial shaft seal Elastomers: FKM Storage: multi-layer MD Pumping medium: ISO VG 320 lubricating oil Viscosity: 50-1000 cSt Temperature: 10-60° C Flow rate: approx. 90/108 l/min. Pressure: 5 bar Speed: 1450/1740 rpm. Pressure relief valve: 6 bar opening pressure Direction of rotation: right Test run: yes, with HLPD 46 Pump support with foot: BLF054250135LA21 Coupling: BKUA065-2428-301 Three-phase standard motor: LDM112-04-903 (Birkenbeul) Motor data: Power: 4.0/4.6 kW Speed: 1500/1800 rpm Voltage/frequency: 230/400 volts at 50 Hz Voltage/frequency: 265/460 volts at 60 Hz Efficiency class: IE3 Additional sign without CE and IE3 marking for: Voltage/frequency: 220-240/380-420 volts at 50/60 Hz Voltage/frequency: 250-280/440-480 volts at 60 Hz Protection class: IP 55 Insulation class: F Design: B 5 Aggregate paint: primed Identification plate: ETY924-D-E--PE02 |
