Please Contact Us to Order to offer competitive prices and delivery time for Stahl CraneSystems - SH 3008-20 4/1 L2 / A0343030040 Electric cable number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Stahl CraneSystems |
| Product | SH 3008-20 4/1 L2 / A0343030040 |
| Description | Electric cable |
| Internal code | ONR4918422 |
| Custom code | 84251100 |
| Technical specification | created taking into account the necessary content from the Product Safety Act (Machinery Directive 2006/42/EC, Low Voltage Directive 2014/35/EU), product-related EN standards and BGV. HD class according to DIN EN 13001-2 HD3 M5 engine classification M5 load rating IP protection class IP55 Place of use in the hall Ambient temperature min -20 °C Ambient temperature max +40 °C CE certification HOIST Load capacity 3,200 kg Lifting height (input) 6,000 m Lifting height (max) 6,000 m Slow lifting speed 1.00 m/min Fast lifting speed 6.00 m/min Number of hoists 1 Number of poles 12/2 Hoist motor type H33 Fine stroke power 0.50 kW Main lift output 3.50 kW ED fine stroke 20% ED main lift 50% Feinhub 360 circuits Main stroke 180 circuits Rope diameter 7.0 mm Item ID rope 1/chain 330 005 9 Cable length 27.800 m Hook bottle type H125-4 CHASSIS Electric vehicle version. Short installation height Type KE-S 33 chassis Slow travel speed 6.30 m/min Fast driving speed 25.00 m/min Number of tractors cat 1 Traction drive type complete SF17113123 Fine driving power 0.11 kW Main drive power 0.44 kW ED fine driving 20% ED main driving 40% Cat flange width 306 mm ELECTRICS Contactor control Crane builder protection control yes Hoist motor nominal frequency 60 Hz Traction motor control frequency 60 Hz Operating voltage 575 V Control voltage 120 V Frequency 60 Hz Stroke Switch Type 125.04 SMC22 overload protection Load measurement sensor LCP/LCD pressure sensor PAINTING Polyurethane coating or SP powder Cat layer thickness 80 µm Body colour RAL 7021, black grey Color of branding parts RAL 6018, yellow green |
