Please Contact Us to Order to offer competitive prices and delivery time for POMPE CUCCHI SRL - SKX015JXHFSL005 Gear pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | POMPE CUCCHI SRL |
| Product | SKX015JXHFSL005 |
| Description | Gear pump |
| Internal code | ONR4437268 |
| Technical specification | Body and cover in AISI 316L machined from rolled bar Mechanical seal in SIC/SIC/EPDM Incoporated bypass valve in AISI 316 Shaft in AISI 316L treated and gears in AISI 316L treated Bushes in graphite FDA certificate Pump with coupling and lantern for motor form B3/B14 frame 90 Rotation direction clockwise (view motor side) Standard elastic coupling Liquid GLUE Viscosity 30-360 cPs Flow SEE BELOW Differetial pressure 10 BAR Connections orientation horizontal Connections 3/4" BSP Pump painting RAL unpainted SUITABLE FOR CLEANING WITH UREA AND HOT WATER AT 60°C PUMPED LIQUID: UREA AND FORMALDEHYDE + MELAMINE POLICONDENSATE RESIN THEORETICAL PUMP CAPACITY 12,4 cm³/rev >>>>>>>>>>>>>>>>>>>>>>>>>>>>>> ACTUAL PUMP CAPACITY - 15 Lt/min (*) @ 1400 RPM 4 POLES MOTOR) - 6 Lt/min (*) @ 700 RPM WITH AN 8 POLE MOTOR (*) ACCORDING ALSO TO PUMPED LIQUID VISCOSITY VALUE |
