Please Contact Us to Order to offer competitive prices and delivery time for Steimel - AT1-182040R / T1-60G-GKGM number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Steimel |
| Product | AT1-182040R / T1-60G-GKGM |
| Internal code | ONR4625171 |
| Custom code | 84136039 |
| Technical specification | ATEX aggregate PTFE, GD, EC, AW, G3/4, M37GN/10, M.Ybx469, MR3Z02.0-386 rpm Gear pumps - aggregate: T 1 - 60/G - GKGM according to Directive 2014/34/EU (ATEX) Item number: AT1-182040R Dimension sheet: DPA001-182040R Spare parts list (pump only): DET001-A031R Operating instructions: DBA-ZP02 + DBA-ZP-ATEX-01 Suction and discharge connection: G ¾ Material finish: Housing parts: EN-GJL-250 (EN-JL 1040) Drive and counter pinion: 16 MnCrs 5, hardened straight-toothed Shaft seal: mechanical seal M 37 GN/10+K+R Q12Q1KGG1 Elastomers of the mechanical seal: Kalrez temperature monitoring on the mechanical seals: 1 PTC thermistor (ATEX), BTW062 wired to Ex terminal box, NAT: 100 °C iBexu 14 ATEX 1291X Display device: on-site Bearing Bushings: Bronze AW increased bearing clearance: without Case seal: Loctite other elastomers: PTFE Extraction hole: without Pumped medium: paints and varnishes solvent-based, pigment-containing, max. 100 μm grain size Concentration: 10 - 70% Viscosity: 1,000 - 2,000 mm2/s Temperature: max. 70 degrees C rinsing with solvent (viscosity 30 - 1000 mm2/s) approx. 10% of the passage of time Delivery data: Q: 0 - 300 L/h p: 0 - 3 bar (pump must suck) n: 0 - 250 rpm direction of rotation: right Test run: yes, with HLPD 46 Pre-cleaning: rinse with mineral spirits Base plate: EGP913045-21BB05 base plate with vibration dampers for free installation on indoor floors article - no.: ILW040x30x55und 4x Ø14 Dispatch fixing holes Coupling: BKUP078-1020-001 Clutch protection: BKS918100080AC01 (sheet brass tread resistant) Pad: EUL—032100BB01 plaromaster ball roller gearbox with intermediate gear and motor Make: Planetroll with ATEX - attesting Type: 0.37D2 (Ex) MR3Z02 - 3, 109 - 1 Product no.: LGM037MR3—001 engine data Power P: 0.37 kW output speed n: 0 - 386 rpm Rated speed - motor n: 2825 rpm Voltage U: 230/400 volts Frequency f: 50 Hz Degree of protection: IP 55 Insulation class: F explosion-proof: Ex e II T 3 Design: B 3 Control element:type HVK, analog display, coarse scale 0-12, fine scale 0-100, viewing window at the top ATEX nameplate: Enter control range Paint: RAL 5009 (HDE) Silicone-free pump! The pump was tested with mineral oil and must be flushed on site before commissioning! Sign: EAY924-PL02 Identification plate: ETY924-D-E—PE03 ATEX marking: II 2G Ex h IIB T3 Gb Please observe the provisions of Directive 2014/34/EU (ATEX) regarding the use of our pumps in hazardous areas. Prerequisite for operation according to: Ex zone 1 (gas), temperature class T 3, Ambient temperature -20 to 40°C Explosion group IIB. Attention: Before starting the pump, the temperature monitoring can be connected functionally! |
