Please Contact Us to Order to offer competitive prices and delivery time for Settima - GR32 SMT 16B 35L AC19/B5 screw pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Settima |
| Product | GR32 SMT 16B 35L AC19/B5 |
| Description | screw pump |
| Internal code | ONR4907332 |
| Custom code | 84136070 |
| Technical specification | Q/P (1450 rpm; 46 mm²/s; 10 bar) =20.73l/min/0.55kW, NPSH=1.83mWS Q/P (1450 rpm; 257.6 mm²/s; 10 bar) =21.15 l/min/0.7 kW, NPSH = 2.3 mWS GR32 = frame size SMT 16B = pressure level 40 bar 35L = nominal flow AC19/B5 = Direct attachment to electric motor /B5 (ø200) aluminum housing SAE pressure port 1 3000psi Standard suction housing with SAE connection 11/4 3000psi NBR sealing material |
