Please Contact Us to Order to offer competitive prices and delivery time for Leybold - TRIVAC D 16 B. number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Leybold |
| Product | TRIVAC D 16 B. |
| Internal code | ONR1807569 |
| Weight | 37 |
| Technical specification | D16B,w/1HP,1PH SPEC MOT Two-stage rotary vane pump Characteristics: Oil-sealed vacuum pump with integrated oil pump for force lubrication of the bearings also at high intake pressures of 1013 mbar. The pump is free of non-ferrous metals and the inside section of the pump is metal-sealed, i.e. there are no elastomeric seals prone to chemical attack. The TRIVAC B pump is equipped with a gas ballast facility through which it is possible to pump condensable gases, and a hydro-pneumatic intake valve for vacuum protection. The pump is additionally certified in accordance with: Category 3 of the EC Directive 94/9/EG (ATEX95). ATEX II(i)3G IIC T4 (50 Hz) T3 (60 Hz) (12°C < Ta < 40°C) X According to its classification, the vacuum pump must not be operated in explosion hazard areas Certification of the motor: CE, CSA, UR Certifications of the pump: ATEX 3i RoHS compliant Technical data: Pumping speed in acc. w. DIN 28400: 16.5 m³/h (50 Hz) / 19.8 m³/h (60 Hz) Ultimate partial pressure without gas ballast: 10-4 mbar Ultimate total pressure with gas ballast: < 5·10-3 mbar Noise level in acc. w. DIN 45 635 without/with gas ballast: 54 / 56 dB(A) Dimensions (LxWxH): 584 x 186 x 250 mm Oil filling min/max: 0.5 / 1.0 l Including oil filling with LVO 310 Motor data: Nominal power rating for the dual motor: 750 W Nominal speed: 1500 rpm (50 Hz) / 1800 rpm (60 Hz) and on-off switch Ingress protection rating: IP44 110 V; 50 Hz; 15 A / 115 V; 60 Hz; 12.4 A 220 V; 50 Hz; 7.5 A / 208-230 V; 60 Hz; 6.3-6.2 A Multi-pin plug at junction box w/o power cable Suited for mains voltages +/- 5% Intake flange: DN25KF for horizontal and vertical use. Discharge flange: DN25KF for horizontal and vertical use. Cooling: Air Equipment: Manual gas ballast facility (on/off) Inert gas connection for the gas ballast M16x1.5 Inert gas connection for the oil box M16x1.5 Oil drain and oil-fill plug Supplied equipment: Operating Instructions Spare parts list 2 x centring and clamping rings Oil filling Leybonol LVO 310 Optional: As accessory we recommend a main flow oil filterfacility depending on the application OF 4-25 or CF 4-25, which may also be retrofitted to the pump. The oil pump built into the TRIVAC B draws in the oil thereafter pumping it through the oil filter facility, only thereafter the cleaned oil will arrive at the lubricating points of the pump. Thus the oil filter facility will not only extended the service life of the oil, but it will also extend the service life of the entire pump |
